Low-end extension for SYVA
- Two 12″ drivers
- Audio and physical link to Syva via AutoConnect
- 40 Hz LF limit, high power handling, low distortion and thermal compression
- Progressive vent for increased peak SPL, and minimal turbulence noise
- Streamlined design
- Plug-and-play package
- Grey brown, pure white + architectural RAL program
DOSCWith the proprietary DOSC waveguide, the L-Acoustics V-DOSC system was the first line array to operate coherently across the whole audible frequency range. Since 1993, this major technological innovation is at the heart of every L-Acoustics line source element, with specifically tailored DOSC waveguides for constant curvature arrays (ARCS systems) or variable curvature arrays (K systems).
Laminar VentingAll current L-Acoustics loudspeaker enclosures with low-range capacities feature laminar vents which provide high SPL while eliminating turbulence noise. This technology was implemented for the first time in 2007 in the SB28 subwoofer, and has been included in K1, K1-SB, K2, SB15m, SB18(i/m), and the X Series.
L-FinsIntroduced in 2008 with the KI system, the L-Fin waveguide marked the transition from the "V" transducer layout of legacy V-DOSC and dV-DOSC systems to the "K" transducer layout. L-Fins significantly improve the precision and smoothness of the directivity pattern in the horizontal plane. In addition to K1, L-Fins are featured in Kara and ARCS WiFo.
DOWNLOAD CENTERSystem Spec Sheet Architect specifications Product Information Pack User Manual Rigging manual Configurations Ease database IP and UV ratings
CENTRE DE TÉLÉCHARGEMENTFiche technique Système Descriptif Architecte Pack Information Produit Manuel d'utilisation Manuel d'accrochage Configurations Base de données EASE Indices IP et UV
Syva is a colinear system suited to medium throw applications. It is designed for professional sound reinforcement and high-end residential applications requiring high fidelity and SPL with minimum impact.
Syva features six 5" MF speakers providing usable bandwidth to 87 Hz and three 1.75" HF diaphragm compression drivers, loaded by DOSC waveguides in a J-shaped progressive curvature. This transducer arrangement produces an H/V 140° x 26° (+5/-21°) directivity pattern, optimized for ultra-wide horizontal coverage with extended throw capability.
Its companion Syva Low enclosure features two K2 12” drivers designed to provide low frequency contour and extended bandwidth down to 40 Hz. Syva Sub features one high-excursion 12” driver equipped with a KS28 woofer motor to further extend the bandwidth of the system in the sub frequency domain down to 27 Hz.
Syva can be wall- or pole-mounted, as well as flown, or used alone with its baseplate. Alternatively, Syva can be rapidly mounted on top of Syva Low or Syva Sub using the AutoConnect plug-and-play audio and physical link.
“The introduction of Syva is a landmark for L-Acoustics. Syva is a new breed of sound system combining the benefits of line source technology with a plug-and-play approach, in a sleek design, tailor-made for places where elegance and discretion are paramount.”
Stéphane Ecalle, Marketing Director at L-Acoustics
